LAUNCH X431 PRO3S+SMARTLINK HD is the upgraded of LAUNCH X431 PRO3S+HDIII. LAUNCH TOP Scanner X431 PRO3S+Smartlink HD ranks No.1 in vehicle coverage. THE 1ST PASSENGER & COMMERCIAL VEHICLES 2IN1 HIGH-END BIDIRECTIONAL SCAN TOOL for 12V cars and 24V Heavy-duty trucks. It supports Full Bi-directional Control + Over 60 Reset/Service Functions + Actuation Test + Adaptation+ Matching+ Reset + Initialization +OE-LEVEL Component Matching+Programmable Module Installation+Online Coding+ SCN Coding+Online Account Login Service+Online Calibration+Online Parameterization+Anti-theft IMMO Serivce+Guided Functions+Power Balance++Offline Coding+Flash Hidden Functions...
From Hardware
PRO3S+Smartlink HD 8+ EXTENSION MODULES
FCA Secure Gateway
LAUNCH X431 PRO3S+ SMARTLINK HD 2.0 automotive diagnostic scanner provides a trustworthy authority for technicians, car dealers, automotive engineers, and service shops to undo the SGW and perform all the necessary repair procedures.
Renault Security Gateway Function
Renault Security Gateway Function is used for unlocking Renault’s gateway to perform service functions, active tests, coding, etc. without the need for a dongle or PC. With this feature, the car scan tool X431PRO3S+SMARTLINK HD allows you to pay to perform those functions via one-click on these models (after 2019), such as CLIO V, CAPTUR II, CAPTUR II CN, MEGANE IV ph2, ESPACE V ph2, TALISMAN/SM6 ph2, NEW ZOE, ARKANA CN, XM3/NEW ARKANA, NEW SANDERO/LOGAN, etc.
Level-up Functions added in 2024:
With ECU coding functions, LAUNCH X431 PRO3S+Smartlink HD will improve vehicle performance, customize individual customization, refresh hidden functions, disable the annoying functions, reprograms the adaptive data for certain components after repairs or replacements, customized configurations for high-end models,etc to enhance fuel efficiency and ensure safe driving.
>>Online Coding: this LAUNCH scan tloo can directly access the online vehicle repair data to do high-level repairs.
>>Offline Coding: read the code from the original module, and then write the code fo r thenew module,for example ,write a VIN to new ECU.
>>Component Matching:Matching,relearn ,Cali-b-ration, or initia-lization adaptive data for certain components after repair or replacements,such as: suspension cali-bration ,seat matching ,sunroof initia-lization,gearbox matching,injector cali-bration, transmission adap-tion.Delete Adapt-ation Data, Tank Cali-b-ration,Height sensor system cali-bration,PSM Sensor Cali-b-ration ,etc.
>>Re-trofit/Modi-fication: for example, re-trofit battery with different type, Upgrading the headlights, taillights, and interior lighting to LED lights,etc.
>>Unlock the hidden features:for example,disable auto start-stop, disable daytime running light, disable safety belt chiming ,delete transport mode,delete transmission adaptive value.setting speed limits,etc.
>>J2534 Programming:Pairing with the SmartLink C V2.0 device (serving as J2534-Compliant VCI), you can operate a PC or LAUNCH X431 PRO3S+SmartLink C diagnostic tool to download OEM software and install J2534 files from LAUNCH official website, to perform the J2534 programming for some vehicles. Note: Reach us to get the J2534 Operation manual.
What can this J2534 Programming Function do for you?(1) Operate OEM programming without using the OEM tools(2) Replace ECUs: program blank ECUs(3) Write-in Data: refresh used ECUs(4) Repair missing ECU information(5) Upgrade ECU software version
>>Audi /VW Firmware Protection Cancel Features:One feature most techs really want is to remove firmware protection from their cars. This feature helps mechanics replace car parts. Carry out car modifications.
>>(PMI) Pro-grammable Module Installation:Support PMI function,Compatible with Ford /Lincoin/ Mazda etc.This function is used when you need to replace a module (replace ECU) or initia-lize a module.No need using the J2534 or buying a subscription.
Bi-directional Control: ( ACTIVE TEST )
--For cars :Injector Buzz Test/Idle Speed Adjustment/Window/Mirror/Door Lock test/Pump and Valve tests/Fuel Pump/Solenoid valve ,tank Ventilation/Switch/cylinder correction off/on/E.GR test/EVAP test/A/C Compressor Activation/Turn on the radiator fan/Modulate the throttle/cycling the a/c/clutch on and off/Acceleration Device Test,etc .(vary by car model,year)
--For Heavy duty Trucks: Cylinder cut-out test/compression test/injector volume commands/injector programming/S.CR commands/rail high pressure test/S.CR catalyst regen/Cylinder balance test/D.PF regen/VGT calibrations/S.CR commands/Aftertreatment reset/Parameter changing/glow relay activation check/reset the D.P.F filter,etc.(vary by car model,year)
Power balance Test : Cylinder power balance testing can help uncover hidden engine issues related to engine misfires, lack of power or just a poor running engine, which is commonly missed with other tests. So, cylinder power balance testing, is one of the best and easiest ways to find the source of a engine misfire. Furthermore, cylinder power balance testing is often used along with a cylinder compression and cylinder leakage tests to further pinpoint the problem. **All above are not available for some specific car models. Reach us for details.
In addition to amazing & powerful diagnostic function, LAUNCH X431 PRO3S+SMARTLINK HD Automotive obd2 scanner also features 60+ service functions to help you complete your repair work at ease. These special functions include but not limited to :
1. Oil Lamp Reset Service: perform reset for a new calculation of Engine Oil Life system once changed the oil.
2. EPB Reset: Help replace and reset the brake pad.
3. BAT battery service(BMS): Clear the fault information of low battery and make it match again
4. D.P.F service
5. SAS Steering Angel Sensor Reset: Reset the steering angle to zero to keep the car running straight.
7. ABS Bleeding: Help exhaust the air.
8. Fuel Injector Coding: Write the new injector code into the car system for correct cylinder injection quantity.
9. TPMS service: Makes sense in displaying sensor IDs from the vehicle's ECU, inputting TPMS sensor replacement IDs and testing sensors.
10. Throttle Adaptation: Initialize the throttle actuators to the default state.
11. AFS Headlamp Reset: Initialize the adaptive headlamp system.
12. Sunroof Initialization: The sunroof needs to be reset when the sunroof control unit have communication problem or changed.
13. Suspension Reset: Adjust the vehicle body height sensor for level calibration.
14. Gearbox Reset: Help complete the gearbox self-learning to improve gear shifting quality.
15. Gear Learning: Monitors certain camshaft position sensors signals.
16. Tire Reset:Set the size parameters of the modified or replaced tire.
17. A/F Reset: Set or learn Air/Fuel ratio parameters.
18. Adblue Reset(Diesel Engine Exhaust Gas Filter): Reset urea after the diesel exhaust treatment fluid is replaced or filled up.
19. Coolant Bleeding: Activate the electronic water pump.
20. Language Change:Change vehicle system language.
21. Nox Sensor Reset: Reset catalytic converter learned value stored in ECU.
22. Stop/Start Reset: Set up the automatic start-stop function in ECU
23. Seat Calibration: Calibrate the memory in replaced or repaired seats.
24. Transport Mode: Deactivate the transport mode.
25. Windows Calibration: Perform door window matching to recover ECU initial memory.
26. AC System Relearn/Initialization.
27. E.GR Reset.
28. Reset Fuel Alcohol Level.
29. Reset Fuel Trim .
30. High Voltage Battery Diagnostics.
31. GPF Regeneration.
32. Camshaft/Crankshaft Sensor Relearn
33. Interactive Vehicle Dynamics (IVD) Initialization Sequence.
34. Fuel Economy Test
35. Halt/Resume Transmission Adaptive Learning.
36. Passive Anti Theft System(PATS)Functions.
37. Relearn Vehicle Data.38.Initialisation Of Automatic Tailgate .
38. Initialise Power Window Regulators;
39. Seat Standardisation 40.Normalise Slide/ Tilt Sunroof;
41. Activate Contactless Vehicle Access
43. Power-Down Command
44. Autoaddressing Ambient Light BDC.
45. Unlocking Auxiliary Heater
46. Drain/ Fill The Refrigerant Circuit
47. Installation Position Of Flap Motors ;
48. ETS Test Of Lithium lon Battery ;
49. Register Battery Exchange 50.Reset Adaptation Values
51. Adjusting The Electromotive Throttle Controller;
52. Injection Quantity Compensation;
53. Open And Close Radiator Blind;
54. Activate/Deactivate Workshop Mode ;
55. Start-Up For Brake Pedal Travel Sensor .etc.>>>>!! Keep Growing with UPDATES !!>>>>>(depending on the specific car models, not for all cars, ). and more and more function will be improved and optimized.
....
300+ Repair Functions For Specific Vehicles (in-vehicle catalog)
Furthermore, the Launch scan tool also developed 300+ functions for specific models. Compared with other diagnostic scanners that can only do the Reset function, the bi-directional scanner can finish deeper and wider Reset, Regeneration, Initiation, Matching, Calibration, Replacement, etc.
>>>>Q: Why do i only see 37 service functions on my tablet, when its advertised 60+ service functions ?
>>>>A: Actually, you can "quick access" to 37 most commonly used special functions under the main menu "service functions", but the listed commonly used special functions below this menu is obviously NOT ALL special functions you will get from our LAUNCH X431 PRO3S+SMARTLINK HD. YES , You can get 60+ for free as we advertised !! (some car models up to 300+ Special functions (Calibration,relearn, adaption ,initialization,retrofit )
>>>>Q: If so , How can I locate the 60+ or even more special functions ?
>>>>A: you can locate more than 60 reset functions (special functions) under module/system after you access to your vehicle software . And it's completely free to use permanently.
Never buy any "special functions“ under "MALL" menu, because you can find all these special functions under the model software and use them for free all your life. If you have any questions about this, please reach to us and we will help you as always. ***Note: Functions are not compatibility with all vehicles, please send car make, year, model, VIN# and functions you need to us to check vehicle compatibility.
One Tool to Cover 99% of Cars! Compatible with a Wide Range of Vehicles
When choosing an car scanner diagnostic for all cars, one of the most important considerations is how compatible it is with different vehicles. This LAUNCH diagnostic tool has expend vehicle coverage, being well-matched with over 99% of popular cars from America, Europe, and Asia, even the most recent models till 2024.COMPATIBLE WITH CARS/TRUCKS/BUSES/TRAILERS/EXCAVATORS/DIESEL ENGINE/CONSTRUCTION MACHINERY/PICK-UP/HYBRID VEHICLE,etc.
Here is the Vehicle List :
AUDI、AUSTFORD、AUSTHOLDEN、AUTOSEARCH、BENZ、BMW、BXFIAT、CHANGAN、CHANGCHENG、CHANGHE、CHRYSLER、CITROEN、CUMMINS、DACHAI、DAEWOO、DAF、DAIHATSU、DEMO、DFL、DR、DS_USAFORD、ECUAID、EOBD2、FAWJIEFANG、FERRARI、FIAT、FLYER、FOTONAUMAN、FUTIAN、GAZ、GM、HAFEI、HD_ABS、HD_ALLISON、HD_ASHOK_LEYLAND、HD_ASTRA、HD_BENZ、HD_BONLUCK、HD_BOSCH、HD_BREMACH、HD_CATERPILLAR、HD_CHAOCHAI、HD_CREDO、HD_DEMO、HD_DETROIT、HD_ERF、HD_FREIGHTLINER、HD_FUSO、HD_GOLDENDRAGON、HD_HIGER、HD_HINO、HD_HYUNDAI、HD_INTERNATIONAL、HD_IRISBUS、HD_IRIZAR、HD_ISUZU、HD_IVECO、HD_JMC、HD_KENWORTH、HD_MACHINERY、HD_MAN、HD_NEOPLAN、HD_OBD、HD_QUANCHAITY、HD_RENAULT、HD_SCR、HD_SETRA、HD_SITCAR、HD_STERLING、HD_SUNLONG、HD_SUNWIN、HD_TATA、HD_VOLVO、HD_WESTERN_STAR、HD_XICHAI、HD_YANGCHAI、HD_YUFENG、HD_ZHONGTONG、HD_DOOSAN、HD_PETERBILT、HD_WABCO_ABS、HM、HMAZDA、HONDA、HUACHEN、HYUNDAI、IKCO、INDIANMAHINDRA、INDIANMARUTI、INDIANTATA、ISUZU、IVECO、JACTY、JAC_HD、JIAO、JINLONG、JOYLONG、JPISUZU、KIA、LANDROVER、LIFAN、LIUWEI_TY、LUXGEN、MACK、MAHINDRA、MALAYSIA、PERODUA、MALAYSIA、PROTON、MARUTI、MASERATI、MAXUS、MAZDA、MITSUBISHI、MVM、NISSAN、OPEL、PERODUA、PEUGEOT、PORSCHE、PROTON、QIRUI_TY、QOROS、RENAULT、RESETAFS、RESETBLEED、RESETBMS、RESETBOX、RESETBRAKE、RESETDPF、RESETETS、RESETGEAR、RESETINJEC、RESETOIL、RESETSAS、RESETSUN、RESETSUS、RESETTPMS、ROVER、SAAB、SAICMG、SAIPA、SCANIA、SEAT、SGM、SHANGCHAI、SINOTRUK、SKODA、SMART、SPRINTER、SSANGYONG、SUBARU、SUZUKI、TATA、TOYOTA、UD、USAFORD、VAZ、VOLVO、VW、WEILI、WP_DIESEL、XIALI、XINKAI、YUCHAI、ZHONGSHUN、ZHONGTAI、ZHONGXING、MAXXFORCE、JOHN、DEER、BENDIX...
LAUNCH X431 PRO3S+ SMARTLINK HD 2.0 scan tool Commercial vehicle Part :
1)Engine diagnosis 2)Natural gas diagnosis 3)Post-processing diagnosis 4)Calibration function: support Chaochai calibration, Dongfeng Renault calibration, Cummins calibration, Shangchai calibration, Weichai calibration, Xichai calibration, Yuchai calibration, heavy truck calibration, Yangchai calibration, etc.; 5)ECU refresh /re-writing: support Bosch ECU brush writing, Nanyue single pump ECU brush writing, Bosch bottom layer brush writing, natural gas ECU brush writing, electric ECU brush writing, Del-phi ECU brush writing, China National Heavy Duty Truck ECU brush writing, Tenneco DCU Wait;
New CAN FD & DoIP Protocol Supporting(NO Need Adapter)
LAUNCH scanners are always connected with the needs of their customers.2024 Upgraded version of LAUNCH X431PRO3S+ Smartlink HD introduces new protocols CAN FD & DoIP to the vehicle diagnostic process for enhancing vehicle diagnostic speed and vehicle communication rate.
CAN FD standard in LAUNCH X431PRO3S+ Smartlink HD increases bit rate of up to 4 Mbit/s during payload transmission and processes greater quantities of diagnostic data, and saves both time and costs. compatible with GM Models including Onix 2020-2024, Tracker 2020-2024, Suburban 2021-2024, Tahoe 2021-2024, Montana 2024, Silverado 2024, Electra E5 2024, Escalade 2021-2024, Escalade ESV 2021-2024, Sierra 2024, Yukon 2021-202.2/2024, Yukon XL 2021-202.2/2024, and Chrysler Models including Grand Cherokee(WL) 2021-202.3, Grand Wagoneer 2022-2024.DoIP allows your LAUNCH X431PRO3S+ Smartlink HD scanner to run a 100Mbit/s ultra-faster data transfer rates at a low hardware cost and achieve remote vehicle diagnostics capabilities in all ECUs connected to it. Compatible with BMW (F&G chassis), Volvo models (2018 later), Land Rover & Jaguar models (2017 later).
FCA Secure Gateway
LAUNCH X431 PRO3S+ SMARTLINK HD 2.0 automotive diagnostic scanner provides a trustworthy authority for technicians, car dealers, automotive engineers, and service shops to undo the SGW and perform all the necessary repair procedures.
Renault Security Gateway Function
Renault Security Gateway Function is used for unlocking Renault’s gateway to perform service functions, active tests, coding, etc. without the need for a dongle or PC. With this feature, the car scan tool X431PRO3S+SMARTLINK HD allows you to pay to perform those functions via one-click on these models (after 2019), such as CLIO V, CAPTUR II, CAPTUR II CN, MEGANE IV ph2, ESPACE V ph2, TALISMAN/SM6 ph2, NEW ZOE, ARKANA CN, XM3/NEW ARKANA, NEW SANDERO/LOGAN, etc.
Launch SmartLink C 2.0 Vehicle List
88 supported software list:
X431, JCB X431, Renault Heavy Vehicle X431, IRIZAR Heavy Vehicle X431, Zhongtong Bus (ZHONGTONG BUS) X431, USAFORD Diesel Version X431, AISIN Heavy Vehicle
X431, Yutong Bus X431, Foton Auman X431, IRISBUS Heavy Duty Truck X431, Kenworth Heavy Duty Truck X431, HD_TATA X431, VOITH Heavy Duty Truck
X431, Benz heavy truck X431, JAC heavy truck X431, CREDO heavy truck X431, Stirling heavy truck X431, Doosan engine X431 Perkins
X431, VOLVO Heavy Duty Truck X431, Freightliner Heavy Duty Truck X431, Dongfeng Commercial Vehicle X431, IWC Heavy Duty Truck X431, Peterbilt Heavy Duty Truck X431, DEUTZ
X431, Cummins engine X431, SCANIA X431, Chaochai X431, Xixing heavy-duty vehicle X431, WABCO ABS X431, ZF
X431, ISUZU Heavy Duty Vehicle X431, FUSO X431, Xichai X431, AutoSearch X431, Case X431, KNORR ABS
X431, IVECO Heavy Duty Vehicle X431, ASTRA X431, Quanchai X431, Dachai Heavy Duty Vehicle X431, Steyr X431, Miller
X431, special for Yuchai X431, BREMACH X-431, Dongfeng Yufeng X431, Golden Passenger Car X431, heavy-duty natural gas X431, HD_FLEXICOIL
X431, BOSCH X431, Hino X431, BONLUCK Bus X431, Higer Bus X431, DENSO_Diesel/Diesel Engine X431, Volvo Construction Machinery
X431, Shangchai X431, ERF X431, ALLISON gearbox X431, Ashok Leyland X431, DELPHI X431, MWM heavy duty vehicles
X431,DAF X431,UD Truck/Nissan Diesel X431,DETROIT Engine X431,Yang Diesel Engine X431,King Long Bus X431,Heavy Truck Demonstration Software
X431, FAW Jiefang X431, construction machinery X431, MACK heavy-duty vehicle X431, HD_ABS system X431, diesel version Mitsubishi X431, heavy-duty vehicle standard
X431, Hyundai Heavy Vehicle X431, SETRA Heavy Vehicle X431, WP Diesel Engine X431, Heavy Truck Aftertreatment System X431, Diesel Nissan X431, Commercial Vehicle One-key Scan
X431, Sinotruk X431, SITCAR heavy truck X431, Sunlong Bus (SUNLONG) X431, heavy truck Jiangling X431, diesel version Toyota
X431, MAN X431, NEOPLAN Heavy Duty Truck X431, Sunwin Bus (SUNWIN) X431, Caterpillar Heavy Duty Truck X431, TRAILER Heavy Duty Truck
Technical Parameters
1. Display tablet
Operating system: Android
Memory: 4GB
Storage: 64GB
Screen: 10.1 inch capacitive touch screen with a resolution of 1280 x 800 pixels
Camera: Rear-facing 8.0MP camera
Connectivity: Wi-Fi (802.11a/b/g/n/ac)/Bluetooth/USB
Working temperature: 0℃ ~ 50℃
Storage temperature: -20℃ ~ 70℃
2. VCI module (SmartLink C V2.0)
Working voltage: DC 9~36V
Power consumption: ≤ 6W
Communication: Wireless/Wired connection
Size: 204mm x 110mm x 45mm
Working temperature: -10℃ ~ 50℃
Package List:
1pc x tablet
1pc x SmartLink C V2.0
6pcs x fuses
9pcs x jumpers
1pc x Jumper 10
1pc x OBD16 connector
1pc x IV 30 connector
1pc x Type II OBD9 connector
1pc x OBD6 connector
1pc x CAT9 connector
1pc x BENZ 14 connector
1pc x RENAULT 12 connector
1pc x ISUZU 20 connector
1pc x VOLVO 8 connector
1pc x MAN 12 connector
1pc x MAN 37 connector
1pc x IVECO 38 connector
1pc x HY-16 cable
1pc x M/F 12+16 cable
1pc x USB cable
1pc x Test cable
1pc x Type C to USB cable
1pc x standard power adapter
1pc x OBD main cable
1pc x power cable clips
1pc x lighter
1pc x For K-20 adapter
1pc x For HA-3 adapter
1pc x For G/V-12 adapter
1pc x For FD-6+1 adapter
1pc x For CR-6 adapter
1pc x For TA-17 adapter
1pc x For TA-22 adapter
1pc x For NN-14+16 cable
1pc x For MH-12+16 cable
1pc x For B-20 adapter
1pc x For BZ-38 adapter
1pc x For BZ-14 adapter
Ship from EU/UK/Other Overseas Warehouse
LAUNCH X431 PRO3S+ SmartLink HD is the best LAUNCH diagnostic scanner. It’s compatible with 12V & 24V vehicles all in one and covers the most vehicle models among all X431 tools. Besides, it supports Full Bi-directional control over 60 Reset/Service functions+ actuation Test+ Adaptation+ Matching+ Coding+ Anti-theft IMMO Service+ Guided functions, etc. Here we will mainly show the Actuation Test function.
Car model:
SCANIA heavy-duty truck
Function:
Test windscreen wipers
Test process:
Connect X431 SmartLink C 2.0 to the vehicle diagnostic OBD port, and connect to X431 PRO3S+ Scan Tool via WiFi
Open X-431 HD APP
Go to the “Local Diagnosis” function
Select “Scania” and confirm the Scania diagnostic software (V15.70)
Click “OK” to continue
Connecting the VCI in WiFi mode…
Select CAN Automatic Identification>> System Scan for a full vehicle checkup
Wait a while…
Select VIS>> ENTER
Read the vehicle info (Scania Part number, software number, SN, VIN, hardware number)
Click “OK”
Select Actuation Test>> Windscreen Wipers, Low Speed
Pay attention to the test conditions on the screen
During actuation, the engine RPM and vehicle speed must be 0. If the engine RPM and vehicle speed are recorded or the signal is lost, actuation is impossible.
Select “On” and the value shows “On”.
Select “Off” and the value shows “Off”.
Observe wiper condition
When clicking “On”, the windscreen wipers start working.
When clicking “Off”, the windscreen wipers stop working.
In addition to windscreen wipers, X431 PRO3S+ SmartLink HD also supports actuation test as follows.
